Taillight FAQ

Taillight Adapters

Features:

Multiple power options

• Can connect directly to the taillight output of a dynamo headlight
• Can connect directly to the dynamo.  Other dynamo taillights cannot handle the full power of the dynamo and must be protected by the headlight.  The Sinewave Taillight CAN handle the full dynamo power.
  • This allows you to use the Taillight without a headlight, or to connect the Taillight to the dynamo in parallel with the headlight, so the Taillight will always be on while the headlight can be switched on and off.
• Can connect to a DC power supply, including an eBike controller or USB battery.
  • DC voltage range is 3.5V - 36V

Selectable blinking mode

• The Taillight can be configured in either steady or blinking mode.


Flexible mounting options

• The Taillight can be mounted anywhere on the bike, either directly or with a simple adapter.

Integrated reflector

• The lens doubles as a reflector, providing extra safety even when the Taillight is off.

Small and light

• Diameter = 29mm
• Length = 32mm
• Weight (including wire) = 30g

Made in the USA

• All Sinewave products are made in the USA.

What's included in the box?

• The Taillight comes with an M5x35mm bolt and 2 washers for installation to an eyelet.
• Adapters are available for other mounting locations.
